MODEL

XA 52.3Y

XA 110.3Y

XA 210.3Y

XA 82/220.3Y

Max capacity

52 g

110 g

210 g

82/220 g

Readability

0.01 mg

0.01 mg

0.01 mg

0.01/0.1 mg

Repeatability

0.01 mg

0.02 mg

0.02 mg

0.02/0.08 mg

Linearity

±0.03 mg

±0.07 mg

±0.1 mg

±0.06/0.2 mg

Sensitivity offset

2×10^-6×Rt

Sensitivity temperature drift

1×10^-6/°C×Rt

Sensitivity stability

1×10^-6/Year×Rt

Minimum weight (USP)

60 mg

Minimum weight (U = 1%, k = 2)

4 mg

Weighing chamber dimensions

170×200×220 mm

Pan size

ø 85 mm

Stabilization time

5 s

Sensitivity drift

1ppm/°C in temperature +15 ° ~ +35 °C

Working temperature

+10 ° ~ +40 °C

Atmospheric humidity

40% ~ 80%

Power supply

13.5 ~ 16 V DC / 2.1 A

Adjustment/calibration

internal (automatic)

Display

5.7 touch screen

Interface

2×USB, RS 232, Ethernet, 4Inputs/4Outputs

Net weight/Gross weight

12.7/16.4 kg

Dimensions

542x206x228 mm

Packaging size

715x385x485 mm
