 특징 F-72
(pH/ION,1CH)
9615-10D(표준)
ION전극(옵션)
*F-72,73(Color Type) 기능 - 본체 및 전극 검사가 용이합니다.
- 정기 검사 모드 : JIS / Pharmacopeias / Degital Simulator
- 교정 및 측정을 위한 맞춤형 자동 홀드 기능
- GLP / GMP 호환 및 PC와의 동시 연결
- 디지털 메모리 : 최대 2,000 세트의 측정 데이터를 기록 할 수 있습니다.
- USB-PC 통신 및 USB 메모리
- 다국어 지원 (일본어, 영어, 중국어, 한국어)
| F-72A-S |
|
|---|
pH | Measurement method | Galass electorode method |
|
Measurement range | pH 0.000～14.000 |
|
Display range | pH -2.000～20.000 |
|
Resolution | 0.01/0.001 pH |
|
Auto range select | ○ |
|
Repeatability | ±0.001 pH±1 digit |
|
pH calibration point | 5 |
|
Repeatability check | ○ |
|
Alarm limit of calibration | ○ |
|
Periodical check | ○ |
|
mV(ORP) | Measurement range | ±1999.9 mV |
|
Resolution | 0.1 mV |
|
Repeatability | ±0.1 mV±1 digit |
|
Temperature | Measurement range | 0.0～100.0℃(-30.0～130.0℃） |
|
Resolution | 0.1℃ |
|
Repeatability | ±0.1℃±1 digit |
|
ION | Measurement method | Ion electrode method |
|
Measurement range | 0.00 μg/L～999 g/L (mol/L) |
|
Resolution | Valid numbers 3 digits |
|
Repeatability | ±0.5% ±1 digit |
|
Periodical check | ○ |
|
Calibration curve point | 5 |
|
Addition method measurement | ○ |
|
Input/output | Input(CH) | 1 |
|
USB peripherals
(Communication with PC)*1 | ○ |
|
USB host（USB memory) | ○ |
|
RS-232C(Printer/PC) | ○ |
|
Analog out put | ○ |
|
Data | Memory number | 2,000 |
|
Interval memory | ○ |
|
ID input | ○ |
|
Data search | ○ |
|
Display | Display | Color graphic LCD with capacitive Touch Panel |
|
Multilanguage display | Japanese/English/Chinese/Korean |
|
Function | Navigation function | ○ | | User gide | ○ |
|
Graf display | ○ |
|
Printer connectivity（GLP/GMP） | ○ |
|
Custom printing function | ○ |
|
temperature compensation（Auto/manual) | ○ |
|
AutoHold function | ○ |
|
AutoHold setting | ○ |
|
Stability function (pH/ION) | ○ |
|
Register operator | ○ |
|
Security(pass word） | ○ |
|
Version up function | ○ |
|
Ambient temperature | 0 ℃ ～ 45℃ |
|
Power | AC adaptor 100 ～ 240 V 50/60 Hz |
|
Demensions | 170(W)×174(D)×73(H)mm(Excluding electrode stand and AC adaptor) |
|
Power consumption | Approx. 9.8 VA |
|
Mass of main unit | Approx .700 g |
|
|
