파장범위

365 ~ 880 nm

파장크기

＜ 4 nm

Optical System:

Concentric Spectrometer

파장 정확도

± 1 nm

파장 단위

0.5 nm

파장스캔 속도

분당 200 nm

파장선택

Automatic

파장교정

Automatic

흡광범위

± 0.001  3.2 Abs

흡광정확도

± 0.005 Abs from 0.0 to 0.5 Abs; ± 1% from 0.5 to 2.0 Abs

Stray Light

>2.5 A, <0.3% T @ 400 nm

교정시한

One year

측정모드

Selectable: momentary, constant on

측정항목

Transmittance, absorbance, concentration, pH, mV, and temperature, plus optional wavelength scan and time course graphs

pH 입력

sensION(TM) 5-pin connector

RS-232 출력

Standard 9-pin bi-directional

프린터 출력

Standard 25-pin

요구전력

9 Vdc, 1 Amp, or 95 to 240 Vac, 50/60 Hz, 자동선택

배터리 백업

15-minute backup operation, automatic recharge

Cell Compatibility:

1-inch round, COD/Test N Tube(TM) Vials; AccuVac(1-inch round); immunoassay vials; 1, 2, 5 x 1-cm

화면

320 x 240 graphic display with touch screen

데이터 저장

1000 data points (date, time, results, sample ID, user ID), 10 wavelength scan graphs, 10 time course graphs, 50 user calibrations

크기

19 x 38 x 13.5 cm nominal

방수등급

Meets IP32 rating (splashproof)

무게

1.95 kg

키패드

5 keys for power on/off, backlight on/off, contrast down, contrast up, and pH

샘플크기

9 mm to 25.4 mm round cell holder (included), 1-, 2-, 5-cm rectangular cell holder (optional)

프린터 포트

External serial or parallel

Pour-Thru Cell:

1-inch (optional)

보고서

Donwload stored information in a standard report format. Meets GLP guidelines, including a minimum of: date, time, sample identification tag, analyst initials (3), results, and instrument serial number

실시간정보
(시간,날짜)

Yes

측정환경

10 ~ 40 ℃ (50 ~ 104 ℉); 85%RH, non-condensing

저장환경

-10 ~ 60 ℃ (14 ~ 140 ℉); 85%RH, non-condensing

pH 측정범위

-2.00 ~ 19.99

pH 분해능

0.001, 0.01, 0.1(선택가능)

pH 기울기

48-65 mV/decade (meter allowable)

mV 측정범위(ORP)

-2000 ~ 2000 mV

mV 분해능

0.1 mV

pH/MV(ORP) 정확도

± 1 mV or ± 0.05% of mV reading, whichever is greater

온도측정범위

- 10 ~ 110 ℃ (can also display ℉)

온도분해능

0.1 ℃

온도정확도

± 1.0 ℃
